SFC508HP
5/5
Price inquiry
US$ 63.80
P/N: SFC508HP
8-Ports PoE(802.3at) 10/100/1000Mbps TP
Professional Quality Testing Program for Network Switches.
- Shipping & Delivery
- 1 Years Warranty
Description
Key Features
- 10/100/1000Mbps TP 8-Ports (PoE 802.3at)
- IEEE 802.3at PoE 30.8W 4-Ports (Max. 130W)
- 8-Ports (15.4W Simultaneous), 4-Ports (30.8W Simultaneous)
- 19” Rack Mountable using 19“ Rack Guide
- 100~240VAC Input Power
Product Specifications
Standard | IEEE 802.3 10Base-T IEEE 802.3u 100Base-TX IEEE 802.3ab 1000Base-T IEEE 802.3af, IEEE 802.3at | |
---|---|---|
Interface | RJ45 Ports | 8-Ports 10/100/1000Mbps TP Auto-Negotiation, Auto MDI-X TP/STP Cat. 3,4 5 Cable EIA/TIA-568 100-ohm(100m) |
LED Indicators | Power, FD, Link/Act, Speed, Poe | |
Performance | POE (Power over Ethernet) | POE Power Budget: Max. 130Watt Number of PD@15.4Watt / 8Port Number of PD@30.8Watt / 4Port |
Environmental | Temperature | Operation: 0℃ ~ 60℃ Store: - 20℃ ~ 80℃ |
Humidity | 5 ~ 95% (Non-condensing) | |
Input Voltage | 100~240VAC, 50/60Hz | |
Dimensions | 280mm(W) x 185mm(D) x 44mm(H) |
